Hex Bolts

We offer Hex Head Bolts & Machinery Fasteners that are widely used in automobile, agriculture and electronics industries. These are specially designed keeping in mind the international quality standards and available in various lengths & sizes. Our range of Metal Bolts & Machinery Fasteners is appreciated for their high strength, durability & functionality. Keeping in mind the drawings, specifications, designs, samples and requirements laid down by our clients, we also hold expertise in providing Bolt Fasteners in standardized as well as non standardized forms from cold forging & bar turning.

Specifications :
Threads:
- ISO metric (MM Threads)
- BA threads
- BSW threads (Inches)
- UNC & UNF threads
Material:
- Carbon Steel
- Alloy steel, Stainless Steel
Finish:
- Plain Finish, Zinc plated
- Yellow plated
- Hot Dipped Galvanized

Diameter	M3				M4				M5				M6
k	2				2.8				3.5				4
s max	5.5				7				8				10
e min	6.01				7.66				8.79				11.05
b up to 125	—				14				16				18
b up to 200	—				—				—				24
Length (mm)	Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread
	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc
	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022
6		100				100
8		100			100	100			100	100			100	100
10		100			100	100			100	100			100	100
12		100			100	100			100	100			100	100
14										100			100	100
16		100			100	100			100	100			100	100
18						100			100	100			100	100
20		100			100	100			100	100			100	100
22													100	100
25		100			100	100			100	100	100		100	100
28													100
30		100			100	100	100	100	100	100	100	100	100	100	100	100
35					100	100	100	100	100	100	100	100	100	100	100	100
40					100	100	100	100	100	100	100	100	100	100	100	100
45						100	100	100		100	100	100	100	100	100	100
50						100	100	100		100	100	100	100	100	100	100
55											100	100			100	100
60							100	100			100	100	100	100	100	100
65											100	100		100	100	100
70												100	100	100	100	100
75															100	100
80												100	100	100	100	100
90													100	100	100	100
100													100		100	100
110															50	50
120															50	50
130															50

Diameter	M7				M8				M10				M12
k	4.8				5.3				6.4				7.5
s max	11				13				17				19
e min	12.12				14.38				18.9				21.1
b up to 125	20				22				26				30
b up to 200	26				28				32				36
Length (mm)	Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread
	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc
	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022
10					100	100
12		100			100	100			100	100
14					100	100
16	100	100			100	100			100	100			100	100
18					100	100
20	100	100			100	100			100	100			100	100
22					100	100
25	100	100			100	100			100	100			100	100
30	100	100			100	100		100	100	100			100	100
35	100	100			100	100	100	100	100	100			100	100
40	100	100	100	100	100	100	100	100	100	100	100	100	100	100	100
45			100	100	100	100	100	100	100	100	100	100	100	100	100	100
50			100	100	100	100	100	100	100	100	100	100	100	100	100	100
55					100	100	100	100	100	100	100	100	100	100	100	100
60			100	100	100	100	100	100	100	100	100	100	100	100	100	100
65					100	100	100	100	100	100	100	100	50	50	50	50
70			100		100	100	100	100	100	100	100	100	50	50	50	50
75							100	100	100	100	100	100		50	50	50
80					100	100	100	100	100	100	100	100	50	50	50	50
85											50				50	50
90					100	100	100	100	50	50	50	50	50	50	50	50
100					100	100	100	100	50	50	50	50	50	50	50	50
110							50	50			50	50	50		50	50
120							50	50	50	50	50	50	50	50	50	50
130							50	50			50	50			50	50
140							50	50			50	50	50		50	50
150							50	50	50		50	50			50	50
160							50				50	50	50		50	50
180							50				50	50			25	25
200							50				50	50			25	25

Diameter	M14				M16				M18				M20
k	8.8				10				11.5				12.5
s max	22				24				27				30
e min	24.49				26.75				30.14				33.53
b up to 125	34				38				42				46
b up to 200	40				44				48				52
b over 200	—				57				61				65
Length (mm)	Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread
	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc
	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022
20	50	50			50	50
25	50	50			50	50
30	50	50			50	50			25	25			25	25
35	50	50			50	50			25	25			25	25
40	50	50			50	50			25	25			25	25
45	50	50			50	50			25	25			25	25
50	50	50	50	50	50	50	50	50	25	25			25	25
55	50	50	50	50	50	50	50	50	25	25	25		25	25
60	50	50	50	50	50	50	25	50	25	25	25	25	25	25	25
65			50	50	25	25	25	25			25	25	25	25	25	25
70	50	50	50	50	25	25	25	25	25	25	25	25	25	25	25	25
75		50	50	50	25	25	25	25			25	25			25	25
80	50	50	50	50	25	25	25	25	25	25	25	25	25	25	25	25
85							25								25
90			50	50	25	25	25	25	25	25	25	25	25	25	25	25
95			50
100	50	50	25	50	25	25	25	25	25		25	25	25	25	25	25
110			25	25			25	25			25	25			10	10
120			25	25	25	25	25	25	25		25	25	10	10	10	10
130			25	25	25		25	25			25	25			10	10
140			25	25			25	25			25	25	10		10	10
150			25		25		25	25			25	25			10	10
160			25				25	25			25	25	10		10	10
170							25	25							10	10
180			25				25	25			25		10		10	10
200			25				25				25		10		10	10
210															1
220							1								1
240							1								1
260							1								1	1
280							1								1
300							1								1
320							1								1
340							1								1
360							1								1
380							1								1
400							1								1
470															1
550															1
580															1

Diameter	M22				M24				M27				M30
k	14				15				17				18.7
s max	32				36				41				46
e min	35.72				39.98				45.2				50.85
b up to 125	50				54				60				66
b up to 200	56				60				66				72
b over 200	69				73				79				85
Length (mm)	Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread		Full Thread		Part Thread
	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc	Bare	Zinc
	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022	G001	G002	G021	G022
40	10	10			10	10
45	10	10			10	10
50	10	10			10	10							1
55	10	10			10	10
60	10	10			10	10			5				1	1
65	10	10	10		10	10
70	10	10	10	10	10	10	10	10	5	5			1	1
75			10		10	10	10						1
80	10	10	10	10	10	10	10	10	5				1	1
90			10		10	10	10	10	5		5		1	1	1
100	10		10	10	10	10	10	10	5		5		1	1	1	1
110			10	10			10	10			5				1
120			10	10	10		10	10			5		1		1	1
130			10				10	10							1	1
140	10		10		10		10	10			5				1	1
150			10				10	10							1
160			10				10	10			5				1	1
180			10				10								1
200			10		10		10				1				1	1
220			1				1								1
240			1				1								1
250															1
260			1				1								1
280			1				1								1
300			1				1								1
320							1								1
340							1								1
360							1								1
380							1
400							1
